Product Details:
|
| Condition: | New Corrugated Belt | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service |
|---|---|---|---|
| Type: | 3&5&7 Ply High Speed Corrugated Cardboard Production Line,corrugated Paperboard Production Line | Automatic Grade: | Automatic |
| Driven Type: | Electric | Dimension(l*w*h): | According To Customer Request |
| Highlight: | Corrugated Cardboard Machinery,Corrugated Paperboard Production Line |
||
High-Speed Corrugated Belt With Low Noise Suitable For 3$5 Ply Corrugated Cardboard Production Lines
| Model | YK-C Common edge |
| Thickness | 9-10 mm |
| Material | Synthetics |
| Width | 1400mm-2500mm |
| Heat-resistance | 200℃ |
| Tensile strength | 65Mpa |
| Coefficient of friction | ≥ 0.40µ |
| Weight per unit | (7.5±0.3)kg/㎡ |
|
Air-permeability 40mm water Column |
2.0m³/㎡ min |
| Model | YK-K Kevlar Edge |
| Material | Synthetics |
| Kavlar Edge | 200 mm inwoven aramid edge |
| Thickness | 9-10 mm |
| Width | 1400mm-2500mm |
| Heat-resistance | 200℃ (Kevlar Edge part up to) 350℃ |
| Break strength | 70 Mpa |
| Coefficient of friction | ≥ 0.40µ |
| Weight per unit | (7.5±0.3)kg/㎡ |
| Air-permeability 40mm water Column | 2.0m³/㎡ min |
