Corrugated Sheet 2 Layer Single Facer Line Semi Automatic

ZJ-V5B hydraulic shaftless mill roll stand

1. Adopt hydraulic drive to complete the paper clamping, loosen, remove for the medium, translation left and right and others, the lifting of the paper adopts hydraulic drive.
2. Brake adjustable adopts a multipoint braking system.

 SF-280S fingerless type single facer

1. Adopt vacuum suction structure, with high-pressure strong blower. Suction with a silencer.
2. Base and wallboard cast iron wall, Wallboard thickness130mm, universal Joints.
3. Corrugated roller material adopt 50CrMo Alloy steel
4. Pressure roller ¢ 284mm, surface grinding and chrome-plated; cylinder control and remove up and down, 45 carbon steel materials, quenching (with cushioning devices).


NC-1800 computer sheet cutter machine

1. Can save 200 sets of orders, replace the cutting specifications quickly and accurately, non-stop for a single, and can achieve computer networking, easy production management.
2. Knife shaft drive gear with eccentric shaft installation, to achieve no backlash drive, high transmission accuracy.
3. Cross-cutting knife with the inserts steel blade. Fixed blade flat structure, more stable, more suitable for cutting high weight and high toughness of cardboard, the shear force is small, long blade life.
4. Pull paper roller outsourcing non-slip material, more wear-resistant, accurate size.
