Product Details:
Place of Origin: China
Brand Name: YIKE GROUP
Certification: CE, ISO
Model Number: YK-2500
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD80000
Packaging Details: Plastic Film
Delivery Time: 60 days after deposit
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50 Sets per Month
Contact Now

Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP

Description
Name: Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine Voltage: 220V/380V,Customer's Demand
Type: Thin Blade Slitter Scorer Warranty: 1 Year And Long Life Technical Support
Function: 3/5/7ply Corrugated Cardboard Production Line Keywords: Thin Blade Slitter Scorer Machine
Condition: New Slitter Machine Application: Machinery & Hardware
Blade&scorer: 5/6/7

Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP



YIKE GROUP  Thin Blade Slitter Scorer machine vedio as follow



https://www.youtube.com/watch?v=AvJDblzRsO0&list=PL8ML2Q3G6U489N9bhRi5wZvWYOqqcUtCg



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 0



                         Technical Specifications of Servo Type Slitter Scorer Machihne



width 1800mm 2200mm 2500mm
speed 150,200,250m/min
Blade&scorer 5&8,6&10,7&12
Order change 1s
precision ±0.5mm
Min.slitting 135mm
Min.scorer 0mm
Correction range 200mm
power 25kw 30kw 35kw
machine size 3900*1800*2450 (mm) 4300*1800*2450(mm) 4500*1800*2450(mm)



Function and Characteristic:

High quality touch screen and PLC equipped composing the CNC system,connect
to the production line.
High quality beeline rail guarantees the precision.
memory of orders,realize non-stop automatic or manual change.
Speed synchronizes with board speed.Standard communication interface,easy to
link with management system.
Alloyed steel thin-blades,sharp and long life of over 8 million meters,auto
sharpening
The knife for computer control automatic or manual knife sharpening,edge
trimming knife,improve production efficiency.
Three types of scorers:convex to concave,convex to flat.
Two rows of scorers,realizes minimum scorer spacing is 0mm.
Computer control score-depth,high quality scorer,more steady .
Using the synchronous belt transmission ,low noise,prolong using time.
Standard motorized body left-right rectification system 200mm

Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 1



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 2



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 3





Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 4



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 5





Other type YIKE GROUP  Carton machine Use For Corrugated Cardboard Production Line



CHINA YIKE GROUP CO.,LTD



If any need,pls contact us at any time



wa.me/008613363699514



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 6



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 7



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 8



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 9



Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 10

Speed 250m/Min 2500mm Servo Type Thin Blade Slitter Scorer Corrugated Paperboard Machine From YIKE GROUP 11
