Product Details:
Place of Origin: China
Brand Name: YIKE GROUP
Certification: ISO,CE
Model Number: YK-1224
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set for Automatic Folder Gluer Machine
Price: Negotiation
Packaging Details: Folder Gluer Machine Packages by Plastic Film
Delivery Time: 3 Months for Folder Gluer Machine
Payment Terms: L/C, T/T
Supply Ability: Folder Gluer Machine 50 Sets Per Month

Automatic Folder Gluer Machine For Carton Box From YIKE GROUP

Description
Item: Automatic Folder Gluer Machine Max Cardboard: 1200*2800mm
Mini Cardboard: 300*800mm Use: Making Corrugated Boxes
Voltage: 220V / 380V / 415V Power: 13.5KW
Highlight:

semi automatic folder gluer

,

folder and gluer machine



Automatic Folder Gluer Machine For Carton Box From YIKE GROUP



Automatic Folder Gluer Machine For Carton Box From YIKE GROUP 0





1. Use And Characteristics

  • Adopt to corrugated board A,B,C,AB, three and five layers cardboard
  • Reduce manpower,replace manual stitching box machine.
  • The glue is easy to dry and keep cleaness.
  • The cartons with good paste, strong, smooth.
  • Few people, fast speed, 2 people on paper, 2 peole tied, 2 people back and forth
  • Working load 8hours 100,00pieces.
  • Suitable for export packing such as beverage box, beer box, instant noodles box, ceramic case box etc.



2. Introduction

  • Computer type automatic glue machine is consist of three parts, which is paper feeding part, gluing folding part and counting stacking part.
  • Automatic Computer adjustment paper feeding / fold and glue.
  • Automatic counting and stacking output.



Automatic Folder Gluer Machine For Carton Box From YIKE GROUP 1

3. Features



1)Paper Feeding Section

  • Vaccum suction feeding
  • Elecromagnetic clutch and brake system
  • Scorer wheel adjustment, suit for 2-8mm thinkness paperboard.
  • Second creasing

2)Glue & Folding Section

  • Glue adjustment
  • Stainless steel glue wheel,saving cost
  • High qulity rubber belt, automatic folding
  • Paperboard rectify and creasing rectify device.

Automatic Folder Gluer Machine For Carton Box From YIKE GROUP 2

3)Counter & Stacker Section

  • Digital control,automatic counting.
  • With rectification fuction.
  • Paperboard counting,output by using pneumatic method.



4. Specification



Model 2800 3200
Max. Cardboard 1200*2500mm 1200*2800mm
Mini. Cardboard 300*800mm 300*800mm
Power Required 11.5kw 13.5kw
Speed 150-200 Pcs/min 150-200 Pcs/min
Voltage 220V/380V/415V 220V/380V/415V





Automatic Folder Gluer Machine For Carton Box From YIKE GROUP 3



Automatic Folder Gluer Machine For Carton Box From YIKE GROUP 4



Automatic Folder Gluer Machine For Carton Box From YIKE GROUP 5



Automatic Folder Gluer Machine For Carton Box From YIKE GROUP 6



Automatic Folder Gluer Machine For Carton Box From YIKE GROUP 7





More questions, pls contact with us.
