YIKE Corrugated Box Chain Feeder Water Ink Two Color Printer Manual Slotter Machine

YIKE Corrugated Box Chain Feeder Water Ink Two Color Printer Manual Slotter Machine


This machine absorbs the features of the same model form abroad, especially improves the structure of changing plates. ink supply transmission, and adopts the new design of the whole of machinery and electronic equipment.
Main features
1.printer slotter phase :electric number digital adjust
2. auto ink circulation system 3. combined slotting creasing slitting knives which is easy to change order.
4.The gear of the machine: Auto lubrication with oil
5.Machine body thickness:50mm 6.automatic seperated, pneumatic lock up.

Chain Feed table unit

• Table by a welded steel plate and channel. Table plate thickness: 3.7mm. Channel is China's national standard of 10 # channel steel. Ink Flexo Printing Slotting Machine
• Table length 2380mm, 4 to 5 groups feed chain. Each chain has three push feeder.
• Configuration 2 side cover. Made with 5 # angle iron.
• The forefront of the table with platen spring. Flexographic Printer New Multicolor

Semi-Automatic Letterpress paper printer Chian Machine

• Automatic measurement of the number of cardboard.

Printer unit

• Gear enclosed spray lubrication system, keyless drive design, so that accurate long-term chromatic unchanged. High-speed Ink Printing Slotting Machine Manufacture
• Frequency control system to control becomes easy and flexible. Each group of printing unit is equipped with jogging button for easy control and loaded rubber plate.
• Each printing unit can be electrical separation. Printing Slotting Machine
• High-precision anilox roller. The textured density of anilox roller is 180-300 lines / inch, to ensure the printing effect is clear and beautiful.
• Ink supply system is pneumatic diaphragm pumps, high efficiency, Flexo Printing Slotting Machine saving ink. Automatic cycle supply. Cleaning with clean water can be.
• Automatic uniform system to keep the anilox roller quit. When the machine stop,the anilox roller and rubber roller could running independently for transmission ink and prevent the ink dry out.
• The rubber roller is use high quality hard wearing rubber,and with the middle of a relatively high high-precision grinding. Semi Automatic Carton Flexo Printing Slotting Machine
• Phase institutions is 360-degree Electric adjustment, ergonomic design.


Slotter unit

• Gear enclosed spray lubrication system, keyless drive design, so that accurate long-term chromatic unchanged. High Speed Flexo Printing Slotting(stacking Unit)
• Phase institutions is 360-degree Electric adjustment, ergonomic design.
• Four-blade sync adjustment for carton height.
• Serrated slotted cutter. Thickness: 7mm. Cutting angle blade width: 40mm.


Technical parameter
