Flexo Printing And Die Cutting Machine / Flexo Printer Slotter With Gluer Online

Flexo Printing And Die Cutting Machine / Flexo Printer Slotter With Gluer Online
Flexo Printing And Die Cutting Machine / Flexo Printer Slotter With Gluer Online

Large Image :  Flexo Printing And Die Cutting Machine / Flexo Printer Slotter With Gluer Online

Product Details:
Place of Origin: China
Brand Name: YIKE GROUP
Certification: CE, ISO
Model Number: YX-1624
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set Flexo Folder Gluer Machine
Price: Negotiation
Packaging Details: Flexo Folder Gluer Machine Packages By Plastic Film, Container
Delivery Time: 6 Months For Flexo Folder Gluer Machine
Payment Terms: L/C, T/T
Supply Ability: 20 Sets Per Month For Flexo Folder Gluer Machine

Flexo Printing And Die Cutting Machine / Flexo Printer Slotter With Gluer Online

Description
Name: Flexo Folder Gluer Machine Color: 1-5 Color Option
Min Feeding Size: 400*900MM Other Name: Flexo Printer Slotter With Gluer Inline
Max. Speed: 180pcs/min Usage: Corrugated Casemaker
Max. Feeding Size: 1600*2400MM Wall Thickness: 50MM
High Light:

flexo printing and die cutting machine

,

printing slotting die cutting machine



CHINA YIKE GROUP CO.,LTD

WEB: www.yikegroup.net

Email: info@yikegroup.net

WhatsApp: +86 17743859771


Corrugated Carton Box Making Machine Flexo Printer Slotter Folder Gluer Inline (FFG Inline)

1. FEATURES

Flexo Printer Slotter Folder Gluer Inline (FFG Inline)

  • High production efficiency
  • Low labor intensity and low labor cost.
  • 2-3 people can complete the entire carton production task.
  • The intelligent aspects of the printing press are mainly reflected in the daily work


2. SPECIFICATION



Item YX-920 YX-1224 YX-1624
Wall board thickness 50mm 50mm 50mm
Max Machine Speed (pcs/min) 250 200 180
Economic Working Speed (pcs/min) 200 150 130
Max. Feeding Size (mm) 900X2000 1200×2400 1600X2400
Min. Feeding Size (mm) 300X600 400x900 400X900
Skip-feeding Size (mm) 1200X2000 1400×2400 1800X2400
Standard Plate Thickness (mm) 7.2 7.2 7.2
Min. slotter distance NEGATIVE 300X100X300X100 300X100X300X100 300X100X300X100
Max slotter depth (mm) 600 600 600
Print precision (mm) ±0.3 ±0.3 ±0.3
Slot precision (mm) ±1.0 ±1.0 ±1.0
Die cut precision (mm) ±1.0 ±1.0 ±1.0
Suitable Cardboard Thickness (mm) 2 - 11 2 - 11 2 - 11



3. WHAT CARTONS COULD THE FFG MAKE ?



  • Regular Slotted Container (RSC)
  • Full Overlap Slotted Container (FOL)
  • Half Slotted Container ( HSC )
  • Customized / Diecut Boxes
  • Wrap Around Blank
  • Center Special Slotted Container ( CSSC )
  • 1-2-3 Bottom Container with RSC Top
  • 1-2-3 Bottom Container with Tuck Top
  • Bellows Style Top and Bottom Container
  • Double Cover Container (DC)
  • Full Telescopic Design Style Container ( FTD )
  • One Piece Folder (OPF), Die Cut with Dust and Tuck Flaps
  • Roll End Tray with Tuck Top and Interior Bottom Flaps
  • Reverse Walker Lock with Inside Tuck Top
  • One Piece Folder (OPF)
  • One Piece Folder with Air Cell/End Buffers, Protect All or Bookwrap
  • Roll End Tray with Locking Cover
  • Five Panel Folder (FPF) or Harness Style Five Panel Folder
  • Center Seam FPF
  • Fruit Boxes
  • Pizza Boxes
  • Archive Boxes


4. DETAILS PHOTO

Flexo Printing And Die Cutting Machine / Flexo Printer Slotter With Gluer Online 0










































Any interesting or questions please send us iniquiry, we will give you the feedback within 2 hours.
