YIKE GROUP Automatic Flute Laminating Machine 1300A 1450A 1650A For Beer / Wine Box

YIKE GROUP Automatic Flute Laminating Machine 1300A 1450A 1650A For Beer / Wine Box

YIKE GROUP Automatic Flute Laminating Machine 1300A 1450A 1650A For Beer / Wine Box

Product Details:

Place of Origin: China
Brand Name: YUNXIANG
Certification: CE,ISO
Model Number: YX-1300A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set Automatic Flute Laminator
Packaging Details: Automatic Flute Laminator Packaged by Plastic Film
Delivery Time: Within 1 Month Upon Receipt of Payment
Payment Terms: L/C, T/T
Supply Ability: 20 SETS Flute Laminator Per Month
Contact Now
Detailed Product Description
Type:: Laminating Machine Condition:: New
Packaging Type:: Bags, Cartons, Film Automatic Grade:: Automatic
Name:: Carton Flute Laminator Warranty:: 1 Year
Application:: Apparel, Beverage, Chemical, Co Voltage:: 380V/220V

YUNXIANG 1300A 1450A 1650A Automatic Flute Laminator for Beer / Wine Box



This Full automatic flute laminating machine is used for color top sheets and corrugated paper laminating, top paper adopt scale continuous paper feeding, unique front gauge positioning way to insure the bottom paper never exceed. Easy for operating and maintenance.

YIKE GROUP Automatic Flute Laminating Machine 1300A 1450A 1650A For Beer / Wine Box

  1. The vacuum suction type feeding system can lead the paper accurately into the machine; cycle stacking planes could stack the next paper well in a state of non-stop working, more efficient.
  2. Roller design scientifically, avoid glue fly out when the speed is high.
  3. Pressure Roller adopt one side adjustment, convenient and fast
  4. Rocker controls wash roller’s fluctuation, easy cleaning
  5. Bottom sheet use suction auto feeding, automatic tracking according to the face paper’s speed
  6. New concept front gauge location, position high accuracy, bottom sheet never pull ahead.
  7. Automatic gluing, and the glue can be used circulatory, avoid glue wasting
  8. Machine uses touch-screen/PLC/servo motor control system, circuit system is stable and could display the failure alarmautom atically.
  9. Counter designs scientifically, easy recording the amount you have been worked.



 Model  YX-1300A  YX-1500A  YX-1600A
 Max sheet size  1300*1250mm  1450*1250mm  1650*1250mm
 Min sheet size  400*400mm  400*400mm  400*400mm
 Top sheet thickness  150-600GSM  150-600GSM  150-600GSM
 Bottom sheet thickness  A/B/C/E/F Corrugated paper, Industrial board
 Max speed( sheets/hour)  8000sheet/hour  8000sheet/hour  8000sheet/hour
 Fitting precision  ±1mm  ±1mm  ±1mm
 Dimensions  11.5*2*2.4M  11.5*2.2*2.4M  11.5*2.4*2.4M
 Machine weight  5000kgs  5500kgs  6000kgs
 Machine power  10KW/380V 11KW/380V  12KW/380V



YIKE GROUP Automatic Flute Laminating Machine 1300A 1450A 1650A For Beer / Wine Box





YIKE GROUP Automatic Flute Laminating Machine 1300A 1450A 1650A For Beer / Wine Box

YIKE GROUP Automatic Flute Laminating Machine 1300A 1450A 1650A For Beer / Wine Box



Q1.How could I get a quotation of the flute laminator?
A: Leave us message with your requirement and we would contact you by trade manager or mail.



Q2. Is there price difference of different size of the machine?
A:Yes, for different size of the machine the price would be different.



Q3: What about your after-sale service and trainning?
A: If you purchase our machine, we could dispatch the engineer to your facotry to install the machine and train your operator how to adjust and maintain the machine.



Q4. What is your Warranty terms?
A:We will supply replacement of parts with the machine, and machine warranty would be 12 month starting from the machine BL date. Extended warrenty is avaliable at the time of purchase, please contact us for details.



Q5. What if I did not find the model that I am looking for?
A: Please contact us freely, we could do customized model of the laminator.



Q6. What about the delivery and the packaging?
A:The delivery time is about 30-45 days,the machine would be packed with iron shelf and plastic film.



Q7.What kinds of trade terms are avaliable to you?
A. We could do FOB,CIF and C&F



YIKE GROUP Automatic Flute Laminating Machine 1300A 1450A 1650A For Beer / Wine Box
